When Connecting D-Net (IEEE1394) Compatible devices
The last device in the chain should not be looped back to the TV as the TV may not be able to work with the other devices.
To connect two or more D-Net (IEEE1394) Compatible devices, follow the diagram below.
IEEE1394 cables longer than 14.76 feet (177.16 inches) should not be used between devices.
A maximum 10 D-Net (IEEE1394)
Compatible devices can be connected.
Do not connect D-Net (IEEE1394)
Compatible devices in a way
that creates a loop.
IEEE1394
cable
IEEE1394
cable
IEEE1394
cable
IEEE1394
cable
IEEE1394
cable
IEEE1394
cable
IEEE1394
cable
IEEE1394
cable
IEEE1394
cable
IEEE1394
cable
IEEE1394
cable
IEEE1394
cable
IEEE1394
cable
IEEE1394
cable
