 SYNC :
- INT
- LL : Internal synchronization.
: External line-lock synchronization.
It is not available at the moment.
SPECIAL SETUP
USER PRESET
PRIVACY
DAY/NIGHT
DIS
SYNC
COMM ADJ
IMAGE ADJ
END
OFF
OFF
COLOR
OFF
INT
┘
┘
┘
 COMM ADJ :
COMMUNICATION SETUP
CAM ID
DISP CAM ID
BAUD RATE
UART MODE
RET PKT
1
ON
9600
8 – N – 1
DISABLE
Two synchronization modes are presented,
INTERNAL and EXTERNAL LINE-LOCK.
EXTERNAL LINE-LOCK mode is not available at the moment.
Needed to be upgraded.
Use this feature to select communication protocol
(refer to p.46~p.51 for details).
Position the indicator over ‘COMMUNICATION’ using the UP
or DOWN button.
- CAM ID : Assign an ID number to the camera (1 to 255)
Identification number zero is used for Remote controller setup.
- DISP CAM ID : Displays camera ID on top left
corner of the screen.
- BAUD RATE : Configure baud rate from 2400 /
4800 / 9600 / 19200 / 38400 /
57600 bps.
- UART MODE : Configure parity bit to NON, EVEN,
or ODD, Data bit is set to 8bit, and
stop bit to 1bit. Set the UART
MODE to EVEN if using the
Remote Controller.
- UART MODE :Used to transfer a packet.
- END
