Speco Technologies CVC230HZ User Manual
Page 17
FOCUS SETUP
MODE
ZOOM TRK
ZOOM SPEED
D-ZOOM
DISP ZOOM MAG
ONE-PUSH
ON
FAST
ON
ON
┘
D-ZOOM : Configure magnification limit from x2~x10 using this feature. Po
sition the indicator over ‘D-ZOOM’ using the UP or DOWN butto
n. Set ‘D-ZOOM’ to ‘ON’ and press the SET button to confirm.
FOCUS SETUP
MODE
ZOOM TRK
ZOOM SPEED
D-ZOOM
DISP ZOOM MAG
ZOOM POS INIT
LENS INIT
END
ONE-PUSH
ON
FAST
OFF
ON
OFF
ON
┘
Set ‘ZOOM LIMIT’ to the desired level using the LEFT or RIGHT button.
DISP ZOOM MAG: Use this feature to display the current zoom magnification
level on screen. Position the indicator over ‘DISP ZOOM
MAG’ using the UP or DOWN button. Then set to ON usin
g the LEFT or RIGHT button.
FOCUS SETUP
MODE
ZOOM TRK
ZOOM SPEED
D-ZOOM
DISP ZOOM MAG
ZOOM POS INIT
LENS INIT
END
ONE-PUSH
ON
FAST
OFF
ON
ON
ON
┘
ZOOM POS INIT: Moves to the controlled ZOOM position when the power t
urned on and is a function of the initial ZOOM position co
ntrol
