FOCUS SETUP
MODE
ZOOM TRK
ZOOM SPEED
D-ZOOM
DISP ZOOM MAG
ZOOM POS INIT
LENS INIT
END
ONE-PUSH
ON
FAST
OFF
ON
OFF
ON
┘
LENS INIT: Use this feature to initialize the lens. Position the indicator over L
ENS INIT. Using the UP or Down button. Press the SET button to
confirm.
END: To revert to the main setup menu.
1. Press the SET button to access the main setup menu and then position
the indicator over ‘EXPOSURE’ using the UP or DOWN button.
2. Press the SET button to confirm.
EXPOSURE SETUP
BRIGHTNESS
IRIS
SHUTTER
AGC
SSNR
SENS-UP
END
50 …………
AUTO
---
MIDDLE
MIDDLE
AUTO
┘
BRIGHTNESS: Use this feature to adjust image brightness. Position the in
dicator over ‘BRIGHTNESS’ using the UP or DOWN button
. Then increase or decrease brightness level using the LEF
T or RIGHT button while verifying the changes on screen.
Set END once desired level is obtained.
EXPOSURE SETUP
BRIGHTNESS
IRIS
SHUTTER
AGC
SSNR
SENS-UP
END
50 …………
AUTO
---
MIDDLE
MIDDLE
AUTO
┘
