18
DESCRIPTION OF THE HOT PLATES
TYPE: PFVZ 60
TYPE: PFVZ 70
TYPE: PFVZ 02
1 Radiant electric heating element Ø 145 mm 1200 W
2 Radiant electric heating element Ø 180 mm 1700 W
3 Radiant electric heating element double cooking zone (conc.) Ø 180/120 mm 1700 W (“Hi-light” as well)
4 Radiant electric heating element double cooking zone (oval) Ø 265/170 mm 2200 W
5 Switch for electric element n. 2
6 Switch for electric element n. 1
7 Switch for electric element n. 3
8 Switch for electric element n. 4
9 Residual heat indicator
10 Radiant electric heating element “Hi-light” Ø 145 mm 1200 W
11 Radiant electric heating element “Hi-light” Ø 180 mm 1800 W
12 Radiant electric heating element double cooking zone (oval) “Hi-light” Ø 265/170 mm 2400 W
13 Switch for electric element n. 10
14 Switch for electric element n. 11
15 Radiant electric heating element grill 2200 W
16 Switch for electric element n. 15
