27
MAINTENANCE
Denominations W
Radiant electric heating element Ø 145 mm 1200
Radiant electric heating element Ø 145 mm "Hi-light" 1200
Radiant electric heating element Ø 180 mm 1700
Radiant electric heating element Ø 180 mm "Hi-light" 1800
Radiant electric heating element double cooking zone conc. Ø 180/120 mm ("Hi-light" as well) 1700
Radiant electric heating element double cooking zone oval 265/170 mm 2200
Radiant electric heating element double cooking zone oval 265/170 mm "Hi-light" 2400
TYPE AND SECTION OF THE POWER CABLES (for 4 HEATING ELEMENTS)
(*) keeping in mind the contemporaneousness factor
3 X 2.5 mm 2 (*) 5 X 1.5 mm 2 (*) 4 X 1.5 mm 2 (*)
POWER OF ELECTRICAL COMPONENTS
Before doing any action, disconnect the
appliance from the input power.
7) COMPONENTS SUBSTITUTION
To replace the components lodged in the internal
part, is necessary to take the appliance up from the
furniture, overturn it, loosen the screws and take
away the bottom.
After these actions is possible to work on the plates,
commutators, clamps and input cable.
In case of substitution of the input cable, the
installer must keep the "earth" conductor longer
than "live" ones, and must respect the cautions
in paragraph "ELECTRICAL CONNECTION".
To reassemble the appliance repeat the inverse
process.
8) TECHNICAL CHARACTERISTICS OF
THE ELECTRICAL COMPONENTS
To facilitate the job of the installer we present a
scheme with the characteristics of the components.
Cable type Single phase power Three phase power Three phase power
monofase Trifase Trifase
230 - 240 V ~ 400 – 415 V 3N ~ 400 - 415 V 2N ~
Rubber
H05 RR-F
TYPE AND SECTION OF THE POWER CABLES (for 2 or 1 HEATING ELEMENTS)
(*) keeping in mind the contemporaneousness factor
3 X 1.5 mm 2 (*)
Cable type Single phase power
230 - 240 V ~
Rubber
H05 RR-F
Radiant electric heating element grill 2200
