Composition
Name and Function of Each Section
COLOR DOME CAMERA
COLOR DOME CAMERA
User’s Manual
User’s Manual
11
10
Pan Base
control panning angle of camera
Rotate Base Holding Screw
fix rotated position
Rotate Base
control rotating angle of camera
1. SID-452
2. Instruction Manual
3. M4 Tapping Screws 4EA
4. M4 Machine Screws 4EA
5. Adapter plate
