6

Using the Battery Voltage Tester (Models XC12 and XCS15 only)
Overview

This battery charger has a built-in voltmeter to test your battery’s state of charge. The charger does not have a built in load

tester. As such, a recently charged battery could have a temporarily high voltage due to what is known as “surface charge”.

The voltage of such a battery will gradually drop during the period immediately after the charging system is disengaged.

Consequently, the tester could display inconsistent values for such a battery. For a more accurate reading, the surface

charge should be removed by temporarily creating a load on the battery, such as by turning on lights or other accessories for

a couple of minutes before you read the display. Read it a couple of minutes after you have shut the headlights off.
Testing Sequence: There are four basic steps required to test the battery state of charge:

With the charger unplugged from the AC outlet, connect the charger to the battery following the instructions given in

1.

sections 6 and 7.
Plug the charger AC power cord into the AC outlet, following the instructions given in section 8.

2.

If necessary, press the BATTERY TYPE button until the correct type is indicated.

3.

Read the voltage on the digital display. Keep in mind that this reading is only a battery voltage reading; a false surface

4.

charge may mislead you. We suggest that you turn on the headlights for a couple of minutes before you read the display.

Read it a couple of minutes after you have shut the headlights off. Compare the reading to the chart below.

6 Volt Battery Voltage

Reading

12 Volt Battery Voltage

Reading

Battery Condition

6.4 or More

12.8 or More

Charged

6.1 to 6.3

12.2 to 12.7

Needs Charging

Less than 6.1

Less than 12.2

Discharged

Tester and Charger: When first turned on, the unit operates only as a tester, not as a charger. To continue to use it only as a

tester, avoid pressing the CHARGE RATE button. Selecting a charge rate activates the battery charger and deactivates the

tester.
Power-Up Idle Time Limit: If no button is pressed within 10 minutes after the battery charger is first powered up, the charger

will automatically switch from tester to charger if a battery is connected. In that case, the charger will be set to charge at the

maintain mode and gel cell battery type.
Testing After Charging: After the unit has been changed from tester to charger (by selecting a charge rate), it remains a

charger. To change the battery charger back to a tester, press the CHARGE RATE button until all charge rate LEDs are off.
Tester Status LED’s: When the unit is operating as a battery tester, the status LED’s light under the following conditions:

The CHARGED LED

does not light in the Battery Test Mode.

The CHARGING LED

does not light in the Battery Test Mode.

The CONNECTED LED

will light if a properly connected battery is detected.

General Charging Notes:
Fan: The charger is designed to control its cooling fan for efficient operation. Consequentially, it is normal for the fan to start

and stop when maintaining a fully charged battery. The fan does not run in Tester Mode. Keep the area near the charger clear

of obstructions to allow the fan to operate efficiently.

CALCULATING CHARGE TIME

12.

Use the following table to more accurately determine the time it will take to bring a battery to full charge. First, identify where

your battery fits into the chart.
NR means that the charger setting is NOT RECOMMENDED.
Find your battery’s rating on the chart below, and note the charge time given for each charger setting. The times given are for

batteries with a 50% charge prior to recharging. Add more time for severely discharged batteries.

Model XC6

BATTERY SIZE/RATING

CHARGE RATE/CHARGING TIME

2 AMP

4 AMP

6 AMP

SMALL

BATTERIES

Motorcycle,

Garden

Tractor, etc.

6 – 12 Ah

2 - 3 ¾ hrs

1 - 2 hrs

45 min - 1 ¼ hrs

12 – 32 Ah

3 ¾ - 10 hrs

2 - 5 hrs

1 ¼ - 3½ hrs

CARS/

TRUCKS

200-315 CCA

40 – 60 RC

11 ¼ - 14 ½ hrs

5 ¾ - 7 ¼ hrs

3 ¾ - 4 ¾ hrs

315-550 CCA

60 – 85 RC

14 ½ - 18 ¼ hrs

7 ¼ - 9 ¼ hrs

4 ¾ - 6 hrs

550-1000 CCA

85 – 190 RC

18 ¼ - 34 ¾ hrs

9 ¼ - 17 ½ hrs

6 - 11 ½ hrs

MARINE/ DEEP-CYCLE

80 RC

17 ½ hrs

8 ¾ hrs

6 hrs

140 RC

27 hrs

13 ½ hrs

9 hrs

160 RC

30 hrs

15 hrs

10 hrs

180 RC

33 hrs

16 ½ hrs

11 hrs
