Radiator, coolers & engine brackets – Scag Power Equipment STT-31BSG User Manual
Page 57
44
1
481810
Radiator
2
481742
Hose, Upper Radiator
3
481743
Hose, Lower Radiator
4
04030-03
Lockwasher, 5/16 (.317 x .586 x .078) Helical Spring
5
422701
Bracket, Air Cleaner
6
422697
Bracket, Engine Mounting LH
7
422698
Bracket, Engine Mounting RH
8
422702
Bracket, Radiator Mounting
9
422704
Shroud, Radiator
10
422696
Plate, Engine Mounting
11
481818
Indicator, Air Cleaner
12
481816
Pre-Cleaner, Engine Air
13
481750
Hose, Air Intake
14
48136-09
Clamp, Hose (2.25” Dia.)
15
422703
Hinge, Hood
16
48136-12
Clamp, Hose (1.50” Dia.)
17
422736
Bracket, Hood Support
18
451120
Bracket, Exhaust Support
19
451121
Clamp Weldment, Muffler (Clamp and Weldment)
48633
Clamp, Muffler (Clamp Only)
20
481827
Elbow, Exhaust
21
451083
Screen, Debris
22
451082
Hood
23
481795
Engine, Briggs & Stratton 31 HP
(Spec. # 580447-0116-E2) Not Available Through Scag, Contact Briggs & Stratton)
24
**
Air Cleaner Assembly w/ Mounting Band (Not Available Through Scag, Contact Briggs & Stratton)
25
04003-12
Bolt, Carr. 5/16-18 x .75”
26
04019-03
Nut, Serr. Flng 5/16-18
27
04069-02
Pin, Rue Cotter 1/2” dia.
28
04090-04
Rivet, Pop 1/8 x .294”
29
481817
Pad, Radiator
30
481924
Adaptor, Pre-Cleaner
31
**
Coolant Tank Assembly w/Hose (Not Available Through Scag, Contact Briggs & Stratton)
32
43508
Spacer, Radiator
33
04002-12
Bolt, Hex Head M8 x 20MM LG
34
482025
Cooler, Oil
35
422715
Engine Spacer
36
481284
Bumper, Rubber
37
04001-08
Bolt, Hex Head 5/16-18 x .75”
38
04003-07
Bolt, Carrage 1/4-20 x .50”
39
04019-02
Nut, 1/4-20 Serrated Flange
40
04001-11
Bolt, Hex Head 5/16-18 x 1.50”
41
04017-16
Bolt, Hex Head 5/16-18 x .75 Serrated Flange
42
04003-04
Bolt, Carrage 5/16-18 x 1.0”
43
04002-10
Nut, 5/16-18 Elastic Stop
44
04040-15
Flatwasher, 5/16 (.375 x .875 x .083)
45
04021-10
Nut, 5/16-18 Elastic Stop
Ref. Part
No. No.
Description
RADIATOR, COOLERS & ENGINE BRACKETS
* Common hardware which should be purchased locally. All bolts Grade 5 plated, all other fasteners zinc plated.
** Purchase through Briggs & Stratton.
