Scag Power Equipment STT-31BSG User Manual
Page 49
36
Ref. Part
No. No.
Description
Ref. Part
No. No.
Description
38
43294
Spindle Housing
39
43312
Spacer, Outside
40
43296
Spacer, Inside
41
481025
Seal, Bottom
42
43297
Spindle Bushing, Bottom
43
481035
Nut, Special 1 - 1/16-18
44
48114-04
Grease Fitting
45
48677
Relief Fitting, Tapered Spindle
46
481050
Spring, Discharge Chute
47
48038
Guide, Roller
48
482001
Cutter Blade, 21.0” 61”
48
482002
Cutter Blade, 24.5" 72”
49
481516
Gearbox Assembly, Deck Drive
50
481558
Belt, Cutter Deck Drive, 61”
50
481980
Belt, Cutter Deck Drive, 72”
51
45944
Roller Shaft
52
48926
Tapered Hub, 1-1/8" Bore
53
48141
Tapered Hub, 1" Bore
54
461174
Idler Arm, Cutter Deck
55
48224
Bearings, Ball
56
48269
Pulley, Idler
57
422713
Base, Idler Pivot
58
48753
Pulley, 6.35 O.D. - 61”
48967
Pulley, 6.95 O.D. - 72”
59
422426
Mounting Plate, Gearbox
60
422413
Belt Cover, LH - 61”
422677
Belt Cover, LH - 72”
422413
Belt Cover, RH - 61”
422708
Belt Cover, RH - 72”
61
461036
Pusharm (includes items 44, 62, 63 & 64)
62
43309
Spacer, Spindle
63
04020-16
Nut, Hex Head 5/8-18 UNF
64
48763
Rod End, 5/8" Male RH Thread
65
04001-79
Bolt, Hex Head 5/8-11 x 4-1/2"
66
481597
Spring, Cutter Deck
67
48753
Pulley, 6.35 O.D. - 61”
48924
Pulley, 5.75 O.D. - 72”
68
04110-03
U-Nut, 3/8-16
69
04021-13
Nut, Hex Elastic Stop 5/8-11
70
422601
Discharge Baffle 61”
422602
Discharge Baffle 72”
1
461267
Cutter Deck, 61” (Includes Decals)
1
461268
Cutter Deck, 61” Advantage (Includes Decals)
1
461144
Cutter Deck, 72” (Includes Decals)
1
461148
Cutter Deck, 72” Advantage (Includes Decals)
2
04003-04
Bolt, Carriage 5/16-18 x 1"
3
04019-04
Nut, Hex Serrated Flange 3/8-16
4
481625-01 Wing nut, 3/8-16
5
481632
Anti-Scalp Wheel
6
04003-26
Bolt, Carriage 3/8-16 x 4"
7
422478
Anti-Scalp Wheel Bracket
8
04017-27
Bolt, Hex Serrated Flange 3/8-16 x 1"
9
04040-10
Flatwasher, 5/8" (.688 x 1.75 x .134)
10
04021-05
Locknut, 3/8-16 Center Lock
11
461292
Discharge Chute, 61” & 72”
461296
Discharge Chute, 61” & 72” Adv. (Not Shown)
12
04001-12
Bolt, Hex Head 5/16-18 x 1.75" (Front)
04001.11
Bolt, Hex Head 5/16-18 x 1.50” (Rear)
13
04021-10
Nut, Hex Elastic Stop 5/16-18
14
04020-09
Nut, 5/8-11 UNC
15
45332
Push Arm Shaft
16
04001-41
Bolt, Hex Head 5/8-11 x 9.50"
17
04003-12
Bolt, Carriage 5/16-18 x .75"
18
04001-154 Bolt, Hex Head 5/16-18 x 4.75"
19
04063-08
Key, 1/4 x 1/4 x 2"
20
04063-01
Key, 1/4 x 1/4 x 1.25"
21
04043-04
Flatwasher,3/8-.39 x .938 x .105 HD
22
04001-11
Bolt, Hex Head 5/16-18 x 1.50"
22A 04001-12
Bolt, Hex Head 5/16-18 x 1.75”
23
04021-10
Nut, Hex Serrated Flange 5/16-18
24
04001-01
Bolt, Hex Head 1/2-20 x .75"
25
48100-15
Bushing, .376 I.D. Oilite
26
04030-03
Lockwasher, 5/16"
27
04040-15
Flatwasher, 5/16" (.375 x .875 x .083)
28
04041-07
Flatwasher, 3/8" (.391 x .938 x .105)
29
04021-09
Nut, Hex Elastic Stop 3/8-16
30
04001-62
Bolt, Hex Head 3/8-16 x 3.25"
31
04001-31
Bolt, Hex Head 3/8-16 x 2.50"
32
43503
Pivot, Idler - Short
33
04001-136 Bolt, Hex Head 3/8-16 x 1.50" Grade 8
34
46631
Spindle Assembly
35
43298
Spindle Shaft
36
481024
Seal, Top
37
481022
Bearing Assembly
* Common hardware which should be purchased locally. All bolts Grade 5 plated, all other fasteners zinc plated.
61”, 61A, 72", 72”A CUTTER DECKS
