37X Speed Dome Camera 46/50
MECHANISM PART
Pan 360°(Endless) Movement
Range
Tilt 90°
Preset 360°/sec.
Jog 0.05 ~ 360°/sec. (Proportional to Zoom) Speed
Swing 1~ 180°/sec.
Preset 127 Presets (Label, Independent Camera Parameter Setting)
Pattern 4 Patterns [1200 Commands(Approx. 5 Minute) / Pattern]
Swing 8 Swings
Group
8 Groups (MAX. 20 Actions with The Combination of Preset,
Pattern and Swing)
Other Pan/Tilt Functions Auto Flip, Auto Parking, Power Up Action and etc.
Communication RS-485 (HTSD37X ONLY)
Protocol Pelco-D, Pelco-P Selectable
OSD English, Menu / PTZ information etc
Sensor Input 3 Inputs, Photo-Coupler Type, DC 5V~12V
Alarm Outputs 1 Output, Relay Output, MAX. Load DC24V 1A / AC125V 0.5A
Fan Always ON
Heater Operation Start from Internal Temperature 10°C
Operating Temperature -22°F ~ +122°F
SPECIFICATIONS 5
