Structure of the Setup Menu
In this chapter, we will look over the Setup Menu of the
SCC-C6407, First we'll look over the overall structure of the
Setup Menu, and then we'll look at the functions of each menu.
Chapter 3 Setup Menu Overview
CAMERA SET
CAMERA ID
ON.../OFF
V-SYNC
INT/LINE...
COLOR/BW
COLOR.../BW.../AUTO...
MOTION DET
ON.../OFF
ZOOM SPEED
1/2/3/4
DIGITAL ZOOM
OFF/X2~X10
DISPLAY ZOOM
OFF/ON
DISPLAY P/T
OFF/ON
EXIT
QUIT/SAVE/PRESET
VIDEO SET
IRIS
ALC.../WDR.../MANU...
SHUTTER
OFF/1/100(1/120)~10K/AUTOX2...~X160...
AGC/MOTION
OFF/LOW/HIGH (AGC)
S.SLOW/SLOW/NORM/FAST/F.FAST(MOTION)
WHITE BAL
ATW1/ATW2/AWC/MANU...
DIS
ON/OFF
FOCUS MODE
ONEAF/MF
SPECIAL
...
REVERSE
OFF/H/V/H/V
Y-LEVEL
(0)l---
C-LEVEL
(0)l---
DETAIL
(0)l---
RET
EXIT
QUIT/SAVE/PRESET
PRESET
POSITION SET
...
PRESET ID
ON.../OFF
VIDEO SET
ON.../OFF
PRESET SPEED
1~8
DWELL TIME
1~60S
IMAGE HOLD
ON/OFF
EXIT
QUIT/SAVE/DEL
ZONE SET
PRIVACY ZONE
...
ZONE DIR SET
OFF/ON...
ZONE AREA SET
OFF/ON...
EXIT
QUIT/SAVE
AUTO SET
AUTO PAN
1.../2.../3.../4...
PATTERN
1.../2.../3...
SCAN
1.../2.../3.../4...
AUTO PLAY
...
RET
