9-27
Chapter 9: Message transfers
9
Set/reset timer/counter (COM = 32
(H)
)
[Format]
COM = 32
(H)
TADR
L, H
= Timer-counter number (0000
(H)
to 03FF
(H)
) See page 9-21.
DATA = Set/reset data (00
(H)
: reset, 01
(H)
: set)
[Function]
- Set/reset the timer/counter displayed on TADR.
[Execution condition]
- Write enable mode
: Mode 1 and mode 2
- PC operation status : Stopping, operating
[Example]
- Set TMR0002.
Ë Command
Ë Response
COM TADR
L
TADR
H
DATA
COM RSLT TADR
L
TADR
H
Ë Command
Ë Response
Set
Timer and counter
number 0002
Timer and counter
number 0002
32 02 00 01
32 00 02 00
