4-7
PCB and Functions
1
2
3
4
5
6
7
8
EMG (CN044)
DISP (CN072)
CHK (CN071)
T10 (CN061)
EXCT (CN073) GRL (CN020)
JP001
FAN DRIVE (CN032)
FILTER (CN070)
POWER LED (D002)
OC (CN040) EEPROM (IC010)
OPTION (CN060)
VARISTOR (VA100)
EEPROM (IC010)
OPTION
(CN060)
CHK
(CN062)
JP001 FILTER
(CN070)
EXCT
(CN073) FAN DRIVE
(CN032)
POWER LED (D002)
DISP
(CN063)
T10
(CN061)
GRL
(CN020) VARISTOR
(VA100)
EMG
(CN044)
OC
(CN040)
2. Indoor Unit Control PCB
1. For AC Fan Motor (CR-UXRP71B-B)
2. For DC Fan Motor (CR-SXRP56B-B)
