Sherwood RD-8601 - Manual (Page 17)

• If removing all punch-through functions is performed
successfully, the LED will flicker twice.
17
Using a punch-through function
This remote control may be programmed to operate
either the AUDIO volume punch-through or the TV
volume and/or TV channel punch-through in
conjunction with any of the eight components
controlled by this remote control.
For example, since this receiver will likely be used as
the sound system while watching TV, you may want to
adjust this receiver’s volume although this remote
control is set to control the TV.
• When programming this remote control for the
AUDIO volume punch-through, press and hold down
both “AUD” button and “VOLUME
” button for
more than 1 second.
• If programming is performed successfully, the LED
will flicker twice.
• When you want either TV volume or TV channel
punch-through, press and hold down both “TV”
button and either “VOLUME
” or “CH/LEVEL
” button for more than 1 second.
Note :
• If you use one of AUDIO and TV volume punch-
through functions, you cannot use the other.
Removing a punch-through function
• When removing the AUDIO volume punch-
through, press and hold down both “AUD” button
and “VOLUME
” button for more than 1 second.
• If removing is performed successfully, the LED
will flicker twice.
• When you want to remove either TV volume or
TV channel punch-through, press and hold down
both “TV” button and either “VOLUME
” or
“CH/LEVEL ” button for more than 1 second.
Removing all punch-through functions
Press and hold down both “AUD” button and
“AUTO” button for more than 1 second.
