ENGLISH
22
C3X Lumis HOST
ELETTRONICS
Input signals:
• 2 COMPOSITEVIDEO (CVBS)
gilded RCA type connectors
1.0 V
pp
/ 75 Ω, negative synchronisation
• 2 S-VIDEO (Y/C)
4 pin mini-DIN connectors
Y: 1.0 V
pp
/ 75 Ω, negative synchronisation
C: 0.286 V
pp
/ 75 Ω, [NTSC burst rated level]
0.3 V
pp
/ 75 Ω [PAL, SECAM burst rated level]
• 1 SETS OF 5 BNC CONNECTORS (YPRPB/RGB)
• 3 SETS OF 5 RCA CONNECTORS (YPRPB/RGB)
- Component signal
Y: 1.0 V
pp
/ 75 Ω, negative or 3 level synchronisation [HDTV]
PrPb:0.7 V
pp
/ 75 Ω
- RGB Signal
R,B:0.7 V
pp
/ 75 Ω
G: 0.7 V
pp
/ 75 Ω, HV synchronisation
1.0 V
pp
/ 75 Ω, negative or 3 level synchronisation [HDTV]
Positive or negativeTTL, 5 V
pp
/ 1 kΩ
• 2 RGBHV (RGB analogic)
female DB15HD-type connectors
R,B: 0.7 V
pp
/ 75 Ω
G:0.7 V
pp
/ 75 Ω, separate H, V or HV synchronisation
1.0 V
pp
/ 75 Ω, negative or 3 level synchronisation [HDTV]
Positive or negativeTTL, 5 V
pp
/ 1 kΩ
• 6 HDMI HDCP
• 1 DVI-D
• 1 SDI
Control:
HOST system: Keypad on rear input panel,
e
m
o
h
r
o
C
P
m
o
rf
2
3
2
S
R
,l
o
rt
n
o
c
e
t
o
m
e
r
automation devices, USB
Projector: Keypad on rear input panel,
e
m
o
h
r
o
C
P
m
o
rf
2
3
2
S
R
,l
o
rt
n
o
c
e
t
o
m
e
r
automation devices
Horizontal frequency:
from 15 to 80 kHz (up to UXGA format @ 65 Hz)
Vertical frequency:
24Hz ~ 30Hz - 48Hz ~ 100Hz
Video standard:
automatic selection (PAL B,G,H,I,M,N,60,
SECAM, NTSC 3.58 and 4.43)
High definition standard:
ATSC HDTV (480p, 720p, 1080i, 1080p)
Graphic standards:
VGA, SVGA, XGA, SXGA, UXGA
Colour temperature:
from 5500K to 9000K
Outputs:
3 jack connectors (12V 100mA) (1 active
when system powered, 1 active when 16:9
aspect ratio selected, 1 for anamorphic
lens on projector rear panel)
Image shift range:
+50% image
14 TECHNICAL SPECIFICATIONS
GENERAL: PROJECTOR
Power cable:
(EU, UK and US); 2m long
Power supply:
from 100 to 240 VAC, +/- 10% toler-
ance
Frequency from 48 to 62 Hz
Power consumption:
420 W Max
Fuse:
FUSE T 10A L H 250V
Dimensions:
458 x 210 x 455 mm (WxHxD)
15,02 x 6,88 x 14,92 inches (WxHxD)
Weight (approx):
11 kg
Operating temperature:
10 to 35°C
Shipping temperature:
-15 to 55°C
Storage temperature:
-15 to 55°C
Humidity:
20% to 95% without condensation
Safety:
EN 60950
Portability:
considered “desktop equipment”
Electromagnetic
compatibility:
EN 55022 Class B
EN 55024
EN 61000-3-2
EN 61000-3-3
UL approval in progress
Transport:
IEC 68-2-31, IEC 68-2-32
GENERAL: HOST
Power cable:
(EU, UK and US); 2m long
Power supply:
from 100 to 240 VAC
+/- 10% tolerance
Frequency from 48 to 62 Hz
Power consumption:
30W max
Fuse:
T 3,15 A H, 5 x 20 mm
Dimensions:
438 x 90 x 301 mm (WxHxD)
14,4 x 32,9 x 11,8 inches (WxHxD)
Weight (approx.):
2,5 Kg
Operating temperature:
10 to 35°C
Shipping temperature:
-15 to 55°C
Storage temperature:
-15 to 55°C
Humidity:
20% to 95% without condensation
Safety:
EN 60950
Portability:
considered “desktop equipment”
Electromagnetic
compatibility:
EN 55022 Class B
EN 55024
EN 61000-3-2
EN 61000-3-3
UL approval in progress
Transport:
IEC 68-2-31, IEC 68-2-32
Manual Version: 460821000 (v1.1)
