7
Putting the plug-on transmitter into operation
Putting the plug-on transmitter into
operation
Inserting the batteries/accupack
For powering the plug-on transmitter, you can either use two 1.5 V AA size
batteries or the rechargeable Sennheiser BA 2015 accupack.
̈
Slide the battery compartment cover
¸
in the direction of the
embossed arrow and open the cover
¸
.
̈
Insert the two batteries or the accupack as shown below. Please
observe correct polarity when inserting the batteries/accupack.
̈
Close the battery compartment.
The battery compartment cover
¸
locks into place with an audible
click.
Charging the accupack
̈
Remove the BA 2015 accupack (optional accessory).
̈
Insert the BA 2015 accupack into the L 2015 charger (accupack and
charger are optional accessories):
Plugging the plug-on transmitter onto a microphone
̈
Plug the microphone’s XLR-3M socket onto the transmitter’s XLR-3F
socket
³
.
̈
Tighten the locking ring
·
in the direction of the arrow.
The L 2015 charger can only charge the BA 2015 accupack. Stan-
dard batteries (primary cells) or individual rechargeable battery
cells cannot be charged.
The transmitter uses the microphone body as an antenna – there-
fore microphones with a metal casing should be used for best
signal transmission.
¸
¸
·
³
