49
Vineyard Seeder
Gearbox Final Assembly
Item Part No. Description Qty.
1 25756 Gearbox Sub-Assembly 1
2 22036 Quadrant, Speed Adjusting 2
3 25754 Lever, Front, Speed Adjusting 1
4 25755 Lever, Rear, Speed Adjusting 1
5 22041 Label, Front, Speed Indicator 1
6 22042 Label, Rear, Speed Indicator 1
7 43366 Tri-Knob, M8, Tapped Centre 2
8 45157 Washer, Flat, M8, Heavy Duty, Zinc Plate 2
9 47031 Bolt, Coach, M8 x 40 Cup Head, Class 4.6, Zinc Plated 2
10 45137 Nut, M8 Nyloc 8
11 45399 Bolt, M8 x 30 Class 4.6, Zinc Plated 6
12 45411S Bolt, M8 x 20 Class 4.6, Zinc Plated 12
13 45151 Washer, Flat, M8, Light 2
14 25762 Gearbox Final Assembly (Includes items 1 to 13 and items 15, to 17) 1
15 27341 Crank Adaptor (Not Illustrated) 1
16 22294 Sprocket Key (Not Illustrated) 1
Pt. No. 67372
Issue 0806
