35
Vineyard Seeder
Mainframe & Wheel Leg Arrangement
Item Part No. Description Qty.
1 27710 Main Frame Assembly 1
2 27280 Front Frame Assembly (Single Coulters) 1
2 27785 Front Frame Assembly (Double Disc) 1
3 18604 Wheel Stud 1/2” x 1 3/4” 8
4 18612 Wheel Nut 1/2” 8
5 Refer Page 36 Wheel Leg & Axle Assemblies 2
6 21467 L/H Link Support Stay 1
7 21468 R/H Link Support Stay 1
8 27455 Rear Link Support Stay 2
9 27778 Top Link Spacer 1
10 45039 M16 x 45 Bolt Class 8.8 6
11 45140 M16 Nyloc Nut 6
12 47237 7/8” x 5 1/2” UNF Bolt 1
13 47548 7/8” UNF Nyloc Nut 1
14 45435 M12 x 40 Bolt 8
15 45139 M12 Nyloc Nut 12
16 21451 Wheel Retraction Stop 2
16 27738 Wheel Retraction Stop (Alternative) 2
17 11760 Buffer Block (Complete with M6 Nyloc) 2
18 19093 Clamp Plate Assembly 2
19 16164 Pin 2
20 45271 R Clip 1
Pt. No. 67372
Issue 0806
Note: Item 16 (27738) is available to give greater lift (70mm approximately)
