6
Creating RAID Array
The SATA II ExpressCard RAID is a two channel Serial
ATA controller that supports two Serial ATA hard disk
drives. It is recommended to use identical hard drives for
all RAID configurations, however, it's possible to combine
hard drives of different sizes and makes. This section
will guide you in setting up a RAID Array.
RAID 0 (Striping)
Striping will erase any existing data on the hard drive.
Make sure you back up your data before striping.
1.
Double click the the SATARAID5 icon on the
desktop to display the SATARAID5 Array
Manager. Before proceeding confirm that both
hard drives display as Available.
2. In the menu bar click RAID Group, click Create
RAID Group then click Yes.
3. In Configuration box, select Striped.
4. In Capacity box, select the desired stripe size. Select
MAX for the maximum capacity.
5. Select Chunk size as determined by your
application. The default of 8 is used in most cases.
6. In Path ID, select both hard disk drives, then click
Create.
7. Click Close, then restart Windows.
When Windows resumes, go to Disk Management on
page 8 to format the RAID Array.
