RAID Group Menu Commands

Create RAID Group
This command displays a dialog box to let user create a

RAID group, the user needs to specify the following

parameters:
RAID Group Label: Provides a name for the RAID

group.
RAID Group: Select a group ID from the available ID list.
Configuration:
Striped: for RAID 0; Mirrored: for RAID 1
Capacity: Select from a list of RAID group sizes. Selecting

MAX will create the largest RAID set possible with the

drives selected.
Chunk Size: Select one size from the available list. This

setting is for RAID 0 (Stripe) set only.
Rebuild Priority: Select from the available list. RAID 0

and virtual disk do not require this. 10 is the highest level

of rebuild priority which means that rebuild times will be

faster but will take more CPU resources to rebuild.
Devices: Select RAID member devices from the available

device segment list.
Rebuild RAID Group
This command displays a dialog box to let the user

choose a replacement segment to rebuild a non-fault

tolerant RAID group.
Delete RAID Group
This command displays a dialog box to let the user

choose RAID groups to delete.
