SIIG 04-0418A User Manual
Page 5
5
RAID Groups window
This window identifies SATA host adapters and
configured RAID groups. Selecting each RAID group in
the RAID Groups window, members consisting of the
RAID group will be highlighted in the Device
Configuration window.
Right clicking on each node in the RAID Groups window,
a popup menu will be displayed to let the user select an
action to be performed for the selected controller or RAID
group.
Device Configuration window
This window identifies all physical drives and their
partitions. A physical drive can be partitioned into
several portions and each portion can be a RAID group
member.
RAID Groups
window
Device Configuration
window
