4-14
H8QM3-2/H8QMi-2 User’s Manual
L3 Cache BG Scrub
Allows L3 cache RAM to be corrected when idle. Options are Disabled
and various times in nanoseconds and microseconds.
DRAM Timing Confi guration
Memory Clock Mode
Allows you to choose between Auto, Limit and Manual for the memory clock
mode.
DRAM Timing Mode
Allows you to choose between Auto, DCT 0, DCT 1 and Both for the DRAM
timing mode.
Alternate VID
Specifi es and alternate VID while in low power states. Options are Auto and
various voltages between .8V and 1.115V.
Memory Timing Parameters
Allows the user to select which CPU Node's timing parameters (memory clock,
etc.) to display. Options are CPU Node 0, CPU Node 1, CPU Node 2 and CPU
Node 3.
SouthBridge/MCP55 Confi guration
CPU/LDT Spread Spectrum
Enables spread spectrum for the CPU/LDT. Options are Center Spread, Down
Spread or Disabled.
PCIE Spread Spectrum
Allows you to Enable or Disable spread spectrum for PCI-Express.
SATA Spread Spectrum
Enables spread spectrum for the SATA. Options are Enabled and Disabled.
PCI Bus Scan Order
Sets the PCI Bus scan order to High Low or Low High.
