4-6
H8QM3-2/H8QMi-2 User’s Manual
MB 3½”, and 2.88 MB 3½".
Floppy B
Move the cursor to these fi elds via up and down
type. The options are Disabled, 360 KB 5 1/4", 1.2 MB 5 1/4", 720 KB 3½", 1.44
MB 3½”, and 2.88 MB 3½".
Onboard Floppy Controller
Use this setting to Enable or Disable the onboard fl oppy controller.
Onboard IDE Controller
There is a single fl oppy controller on the motherboard, which may be Enabled or
Disabled with this setting.
Serial ATA Devices
This setting is used to determine if SATA drives will be used and how many. Op-
tions are Disabled, Device 0, Device 0/1 and Device 0/1/2.
nVidia RAID Function
This setting is used to Enable or Disable the nVidia ROM.
Primary IDE Master/Slave
Highlight one of the items above and press
that item.
Type
Select the type of device connected to the system. The options are Not Installed,
Auto, CDROM and ARMD.
LBA/Large Mode
LBA (Logical Block Addressing) is a method of addressing data on a disk drive.
The options are Disabled and Auto.
Block (Multi-Sector Transfer)
Block mode boosts IDE drive performance by increasing the amount of data
transferred. Only 512 bytes of data can be transferred per interrupt if block mode
is not used. Block mode allows transfers of up to 64 KB per interrupt. Select
Disabled to allow the data to be transferred from and to the device one sector
at a time. Select Auto to allows the data transfer from and to the device occur
multiple sectors at a time if the device supports it.
