4-12
H8QM3-2/H8QMi-2 User’s Manual
Chipset Confi guration
NorthBridge Confi guration
Memory Confi guration
Bank Interleaving
Select Auto to automatically enable interleaving-memory scheme when this
function is supported by the processor. The options are Auto and Disabled.
Channel Interleaving
Select to enable channel interleaving when this function is supported by the
processor. The options are Disabled, Address bits 6, Address bits 12, XOR
of Address bits [20:16:6] and XOR of Address bits [20:16:9].
Enable Clock to All DIMMs
Use this setting to enable unused clocks to all DIMMs, even if some DIMM
slots are unpopulated. Options are Enabled and Disabled.
Mem Clk Tristate C3/ALTVID
Use this setting to Enable or Disable memory clock tristate during C3 and
ALT VID.
Memory Hole Remapping
When "Enabled", this feature enables hardware memory remapping around
the memory hole. Options are Enabled and Disabled.
CS Sparing Enable
Use this setting to Enable or Disable the CS Sparing function.
DCT Unganged Mode
Enabling this setting allows selection of unganged DRAM mode (64-bit width).
Options are Auto and Always.
Power Down Enable
EUse this setting to Enable or Disable the DDR power down mode.
