Woodstock SHOP FOX W1706 - Manual (Page 56)

-54-
Model W1706 (Mfg. Since 3/13)
PA
RT
S
Cabinet.Stand.Parts.List
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 X1706001 CABINET STAND ASSEMBLY 101 X1706101 TRUNNION
1-1 X1706001-1 CABINET STAND 102 X1706102 TILT SCALE
1-2 X1706001-2 CABINET DOOR 103 X1706103 TRUNNION CLAMP SHOE
1-3 X1706001-3 BOTTOM BLACK STRIPE 104 XPB19 HEX BOLT 1/4-20 X 1/2
1-4 X1706001-4 HANDLE 104-1 XPW06 FLAT WASHER 1/4
1-5 X1706001-5 CABINET RUBBER FOOT 105 X1706105 TRUNNION BASE
8 XPK23M KEY 5 X 5 X 25 106 XPB12 HEX BOLT 5/16-18 X 1-1/4
11 X1706011 MOTOR 1HP 110V/220V 1PH 108 X1706108 POINTER
11-1 X1706011-1 MOTOR FAN 109 XPS18 PHLP HD SCR 10-24 X 1/4
11-2 X1706011-2 MOTOR FAN COVER 110 X1706110 TRUNNION LOCK KNOB 3/8-16
11-3 X1706011-3 MOTOR JUNCTION BOX 111 XPB58 HEX BOLT 3/8-16 X 2
11-4 X1706011-4 CAPACITOR COVER 112 XPB22 HEX BOLT 5/16-18 X 1-3/4
11-5 X1706011-5 S CAPACITOR 300M 125V 113 XPN02 HEX NUT 5/16-18
12 X1706012 MOTOR PULLEY 174V2 X1706174V2 MACHINE ID LABEL CSA V2.08.10
13 XPSS07 SET SCREW 1/4-20 X 1/2 175 XLABEL-14 ELECTRICITY LABEL LARGE
25V2 X1706025V2 POWER CORD 16G 3C 5-15 V2.08.10 176 XLABEL-14B ELECTRICITY LABEL SMALL
26V2 X1706026V2 MOTOR CORD 16G 3C V2.08.10 177 XLABEL-03 CLOSE DOOR WARNING LABEL
73 XPLW01 LOCK WASHER 5/16 178 XLABEL-10B BANDSAW ADJUST LABEL
97 X1706097 TABLE 179 XLABEL-17 BLADE DIRECTION LABEL
98 X1706098 LARGE TABLE INSERT 180 XLABEL-07A UNPLUG WARNING LABEL
98-1 X1706098-1 SMALL TABLE INSERT 181 XLABEL-06 RESPIRATOR WARNING LABEL
99 XPRP15M ROLL PIN 3 X 8 182 XLABEL-08 READ MANUAL LABEL SMALL
100 X1706100 TABLE LOCK PIN 184 X1706184 MODEL NUMBER LABEL
Body.Parts.List
REF PART # DESCRIPTION REF PART # DESCRIPTION
2 XPB64 HEX BOLT 5/8-11 X 2-1/2 22 X1706022 WHEEL PULLEY
3 XPW14 FLAT WASHER 5/8 23 XPS22 PHLP HD SCR 10-24 X 5/8
4 XPN04 HEX NUT 5/8-11 24V2 X1706024V2 STRAIN RELIEF V2.08.10
5 X1706005 GUIDE PIN 6 X 5MM 28 X1706028 UPPER FRAME ARM
6 X1706006 LOWER WHEEL SHAFT 29 X1706029 KNOB BOLT 5/16-18 X 3/4
7 XP6204-2RS BALL BEARING 6204-2RS 29-1 X1706029-1 KNOB BOLT 5/16-18 X 2
8 XPK23M KEY 5 X 5 X 25 30 X1706030 TENSION SPRING HOUSING
9 XPW07 FLAT WASHER 5/16 31 XPWN03 WING NUT 5/16-18
10 XPB86 HEX BOLT 5/16-18 X 3/4 33 X1706033 TENSION BOLT 3/8-16 X 11-5/8
14V2 X1706014V2 PUSH BUTTON SWITCH V2.08.10 34 X1706034 PIVOT PIN
15 XPHTEK37 TAP SCREW #10 X 3/4 35 X1706035 UPPER WHEEL SHAFT
16 XPW03 FLAT WASHER #10 35-1 X1706035-1 SHAFT BRACKET
17 XPS01 PHLP HD SCR 10-24 X 1/2 35-2 XPRP73M ROLL PIN 4 X 30
19 XPTLW01 EXT TOOTH WASHER #10 38 X1706038 TENSION SPRING 3.8 X 76
20V2 X1706020V2 SWITCH BOX V2.08.10 39 X1706039 INDICATOR NUT 3/8 X 16
21 X1706021 SWITCH BRACKET 40 X1706040 UPPER WHEEL
