-16-
Model W1706 (Mfg. Since 3/13)
SE
TU
P
Once the assembly is complete, test run your machine to
make sure it runs properly.
If, during the test run, you cannot easily locate the source
of an unusual noise or vibration, stop using the machine
immediately, then review the Troubleshooting on Page.
52.
If you still cannot remedy a problem, contact our Tech
Support at (360) 734-3482 for assistance.
To.test.run.the.machine,.do.these.steps:
1. Make sure you understand the safety instructions
at the beginning of the manual, and verify that the
machine is setup properly.
2. Ensure all tools and objects used during set up are
cleared away from the machine.
3. Turn the machine ON.
4. Listen to and watch for abnormal noises or actions.
The machine should run smoothly with little or no
vibration or rubbing noises.
— Strange or unusual noises should be investigated
and corrected before operating the machine
further. Always disconnect the machine from
power when investigating or correcting potential
problems.
5. Turn the machine OFF.
Test.Run
Projectiles. thrown. from. the. machine.
could. cause. serious. eye. injury.. Wear.
safety. glasses. to. reduce. the. risk. of.
injury.
Loose. hair. and. clothing. could. get.
caught.in.machinery.and.cause.serious.
personal. injury.. Keep. loose. clothing.
rolled. up. and. long. hair. tied. up. and.
away.from.machinery.
Additional.Adjustments
After successfully completing the Test.Run, the
adjustment procedures listed below must be performed to
ensure safe and accurate cutting operations (refer to the
following subsections for detailed instructions):
• Properly tension the blade ( Page.17).
• Adjust the positive stop bolt ( Page.18).
• Align the table with the blade ( Page.19).
• Square the miter gauge body to the blade ( Page.20).
• Align the fence with the blade ( Page.21).
• Adjusting the blade support bearings ( Page.22).
• Adjusting the blade guide bearings ( Page.24).
