Chapter 4: Integrating other devices
Video format compatibility 27
Native video format 28
HD and SD signal format compatibility 29
Video system signal compatibility 29
Connecting peripheral sources and outputs 30
This chapter provides information on integrating your LightRaise 40wi interactive projector with
peripheral devices.
Video format compatibility
The following table lists the projector's compatible VESA® RGB video formats by resolution, which
the projector adjusts automatically when you use the aspect ratio commands described in Adjusting
projector settings on page 13.
Resolution Mode Aspect
ratio Refresh
rate (Hz) Match Input
appearance
(16:10 aspect
ratio mode)
Match Input
appearance
(16:9 aspect
ratio mode)
720 Ч 400 720Ч400_85 9:5 85.039 Letterbox Letterbox
640 × 480 VGA 60 4:3 59.94 Pillarbox Pillarbox
800 × 600 VGA 72 4:3 72.809 Pillarbox Pillarbox
800 × 600 VGA 75 4:3 75 Pillarbox Pillarbox
800 × 600 VGA 85 4:3 85.008 Pillarbox Pillarbox
800 × 600 SVGA 56 4:3 56.25 Pillarbox Pillarbox
800 × 600 SVGA 60 4:3 60.317 Pillarbox Pillarbox
800 × 600 SVGA 72 4:3 72.188 Pillarbox Pillarbox
800 × 600 SVGA 75 4:3 75 Pillarbox Pillarbox
800 × 600 SVGA 85 4:3 85.061 Pillarbox Pillarbox
832 × 624 MAC 16" 4:3 74.55 Pillarbox Pillarbox
