5. Remove the Connectors at the end of the Camera Adaptor.
In the next step, peel off the coating of the cable and connect it to the external cable
using soldering. (See the wiring diagram of the installation guide for the Camera to
connect the cables.)
Lastly, use an insulation tape to wrap up the soldering portion of two cables.
Repeat the above steps to connect all of the 4 Connectors to the appropriate external
cables.
CAMERA ADAPTOR
CAMERA ADAPTOR
CABLE
CONNECTOR
EXTERNAL CABLE
BNC JACK
SOLDERING
CONNECTOR
CONNECTOR
BNC JACK
EXTERNAL CABLE
