Instructions for the installer
40
Twin oven model
The appliance comes with a terminal board on the back for electrical
hook-up (see following diagram). To open the terminal board cover,
remove the fixing screw and raise the cover.
1 - For operation on 230V
∼∼∼∼
: use a three-
pole H05RR-F type cable (3 x 4 mm 2 ). This
is the connection carried out in the
factory.
2 - For operation on 230V3N
∼∼∼∼
: use a four-
pole H05RR-F type cable (4 x 2.5 mm 2 ).
3 - For operation on 400V2N
∼∼∼∼
: use a four-
pole H05RR-F type cable (4 x 2.5 mm
2
).
The cable end to be connected to the
appliance must be provided with an ground
wire (yellow-green) at least 20 mm longer.
