Instructions for the user
45
5. DESCRIPTION OF CONTROLS
5.1 Front control panel
All the cooker controls and commands are on the front panel.
Single oven model
Before using the oven check that the electronic programmer is showing
the symbol
(see paragraph “5.2.1 Clock adjustment”.
DESCRIPTION OF SYMBOLS
FRONT RIGHT BURNER OVEN VARIABLE
GRILL
BACK RIGHT BURNER OVEN THERMOSTAT
BACK LEFT BURNER OVEN FUNCTION
FRONT LEFT BURNER
COOKING HOB BURNER COMMAND KNOB
The flame is lit by pressing the knob and turning it
anticlockwise to maximum flame
. To adjust the
flame turn the knob between maximum ( ) and
minimum ( ). The burner goes out when the knob is
returned to the position
.
