OPERATION

SE10-4A/SE15-4A 03/09

Operation Section 4-47

OPERA

ION

Bent Shaft.

Replace Oil Seal and Shaft.

Oil Seal Race rough.

Replace Shaft or repair Race.

Oil Seal installed wrong.

Replace Seal.

Oil Seal not sealing in the housing.

Replace Seal or use a sealant on O.D.

of Seal.

Oil level too high.

Drain oil to proper level.

Gasket damaged.

Replace Gasket.

Bolts loose.

Tighten Bolts.

Rapid Clevis Wear

Washers not used.

Install washers above & below drawbar

Clevis bending or spreading

Using pin or bolt not tightened.

Use 1” gr5 or 8 bolt & tighten nut.

open.

Tongue bending or binding

Improper Drawbar.

Add attaching Plate to all 3-Point

in turns.

drawbars.

Clutch Slips Excessively

Clutch linings badly worn or

Repair clutch per maintenance section

plates warped.

of manuals.

Too much power for

Reduce ground speed and

Slip Clutch.

material intake.

Oil on Facings.

Replace Facings.

Friction Facings glazed.

Clean with emery cloth.

Oil squirting from breather

Oil leaking by piston ring. (A small

Do not carry cutter on cylinder. (Use

vent hole

amount of leakage is normal.)

stroke control.)

Piston ring worn.

Replace piston ring.

Cylinder wall scored or pitted.

Replace cylinder.

Wrong piston ring on piston.

Use correct piston rings.

Streaking Conditions in Swath

Conditions too wet for cutting.

Allow grass to dry before cutting. Slow

Blades unable to cut that part of

ground speed of tractor but keep

grass pressed down by path of

engine running at full PTO rpm. Move

tractor tires.

rear tires to 60” inside of tires so wing
blades will pick up grass.

Dull blades.

Sharpen or replace blades.

Height of cutter lower at rear or front. See cutting height instructions.

Gearbox Overheating

Low on lubricant.

Fill to level plug.

Improper type lubricant.

Replace with proper lubricant. See
Maintenance Section.

Excessive trash build-up around

Remove trash.

gear box.
Bearing or gears set-up improperly.

Consult your dealer.

Hydraulic Cylinder Will Not

Not enough pressure.

Check pressure.

Operate

Valve not connected properly.

Re-plumb valve.

Quick coupler not completely

Complete connection.

connected.
