DSL/Cable Router User Guide

78

Figure 45: Routing Screen

Data - Routing Screen

RIP

Enable RIP

Check this to enable the RIP (Routing Information Protocol) feature
of the DSL/Cable Router.

The DSL/Cable Router supports RIP 1 only.

Static Routing

Static Routing
Table Entries

This list shows all entries in the Routing Table.

The "Properties" area shows details of the selected item in the

list.

Change any the properties as required, then click the "Update"

button to save the changes to the selected entry.

Properties

Destination Network - The network address of the remote LAN

segment. For standard class "C" LANs, the network address is
the first 3 fields of the Destination IP Address. The 4th (last)
field can be left at 0.

Network Mask - The Network Mask for the remote LAN seg-

ment. For class "C" networks, the default mask is 255.255.255.0

Gateway IP Address - The IP Address of the Gateway or Router

which the DSL/Cable Router must use to communicate with the
destination above. (NOT the router attached to the remote seg-
ment.)

Metric - The number of "hops" (routers) to pass through to reach

the remote LAN segment. The shortest path will be used. The de-
fault value is 1.
