3-30
GB
3-29
DIGITAL VIDEO RECORDER
GB
(3) FROM ALARM EVENT LIST (Backup by the alarm event list)
FROM ALARM EVENT LIST BACK UP is used to back up the video and audio data at
the time of alarm event created by alarm or movement detection in the external SCSI HDD
from the main body HDD. The following screen shows the detailed setup procedure of
FROM ALARM EVENT LIST and the EVENT(RECORD START), date, and time in the
following screen are based on the HDD recording. If you press the MENU button, the
MENU screen will pop up to escape the FROM RECORD EVENT LIST screen.
Press the JOG( ) or UP( ), DOWN( ) button to move the cursor. The selected items
will be highlighted. Once you move to the EVENT LIST part to be backed up, press the
SET/STILL button( ) then the following screen will appear. The following screen
shows an example when you select ID 01 in the above screen.
Please refer to Page 3-26, ‘The TIME RANGE Handling Method’ for the detailed usage of
the above screen.
Set the date and time according to the usage of TIME RANGE and press the JOG( )
or UP( ), DOWN( ) button to move the cursor with [START] in the above screen.
Then if you press the SET/STILL button( ), the backup screen will popup to start
backup process.
Please refer to Page 3-28 for the detailed usage of the backup screen.
ALARM EVENT BACKUP
ID EVENT DATE TIME
01 RECORD START 2003-04-02 13:27:39
02 RECORD START 2003-04-02 13:29:50
03 RECORD START 2003-04-02 14:00:30
04 RECORD START 2003-04-02 15:01:35
EXIT = [MENU] SELECT = [SET/STILL]
TIME RANGE
FROM DATE 2003.04.02
TIME 13:27:39
TO DATE 2003.04.02
TIME 13:27:39
[START]
SYSTEM HDD 70.8GB / 80.8 GB [1]
SCSI HDD
15.1GB / 18.1 GB [1]
(2)FROM RECORD EVENT LIST (Backup by the record event list)
When you press the RECORD key in the main body HDD for recording or you have
recorded data for long, the event list will be created at an interval. If you use this function
for recording, you will be able to locate the backup position more conveniently than TIME
RANGE BACKUP. The following screen illustrates the detailed setup screen of FROM
RECORD EVENT LIST and the EVENT(RECORD START), time, and date are based on
the HDD recording. If you press the MENU button, the MENU screen will pop up to escape
the FROM RECORD EVENT LIST screen.
Press the JOG( ) or UP( ), DOWN( ) button to move the cursor. The selected items
will be highlighted. Once you move to the EVENT LIST part to be backed up, press the
SET/STILL button( ) then the following screen will appear. The following screen
shows an example when you select ID 01 in the above screen.
Please refer to Page 3-26, ‘The TIME RANGE Handling Method’ for the detailed usage of
the above screen.
Set the date and time according to the usage of TIME RANGE and press the JOG( )
or UP( ), DOWN( ) button to move the cursor with [START] in the above screen.
Then if you press the SET/STILL button( ), the backup screen will popup to start
backup process.
Please refer to Page 3-28 for the detailed usage of the backup screen.
RECORD EVENT BACKUP
ID EVENT DATE TIME
01 RECORD START 2003-04-02 13:27:39
02 RECORD START 2003-04-02 13:29:50
03 RECORD START 2003-04-02 14:00:30
04 RECORD START 2003-04-02 15:01:35
EXIT = [MENU] SELECT = [SET/STILL]
TIME RANGE
FROM DATE 2003.04.02
TIME 13:27:39
TO DATE 2003.04.02
TIME 13:27:39
[START]
SYSTEM HDD 70.8GB / 80.8 GB [1]
SCSI HDD
15.1GB / 18.1 GB [1]
