3-28
GB
3-27
DIGITAL VIDEO RECORDER
GB
⑧ Backup Screen
FROM 2003 - 04 - 02 22 : 16 : 32 (Displaying the backup start time)
The TIME RANGE screen displays the backup start time.
TO 2003 - 04 - 02 23 : 00 : 00 (Displaying the backup finish time)
The TIME RANGE screen displays the backup finish time.
CUR 2003 - 04 - 02 22 : 30 : 32 (Displaying the current backup time)
The TIME RANGE screen displays the current backup time.
COPY 50 %DONE(Displaying the backed-up capacity)
The TIME RANGE screen displays how much capacity has been backed up.
CANCEL = [STOP]
You shall press the STOP [ ] button to stop the backup process. If not, the system will
backup the selected capacity by 100% and stop the process automatically. Then it escapes
from the SCSI and shows the LIVE screen.
– During the SCSI backup process, you may not record or replay data in the DVR main body HDD
nor you may communicate through LAN.
– The date and time in the backup screen indicates the time when the main body starts recording in
the HDD.
– The backup process continues until the end of the SCSI HDD. Then replace the SCSI HDD or use
the same SCSI HDD to continue recording. If you use the same SCSI HDD, the system will return
to the initial part of the SCSI HDD while overwriting the existing image record data.
BACKUP
FROM 2003-04-02 22:16:32
TO 2003-04-02 23:00:00
CUR 2003-04-02 22:30:32
COPY 50% DONE
CANCEL=[STOP]
2003-04-03 09:16:12
Caution Caution
① FROM DATE 2003 . 01 . 01 (Backup Start Date)
You can set the date to start backing up the video and audio signal saved in the HDD in the
SCSI HDD.
② TIME12 : 00 : 00 (Backup Start Date)
You can set the date to start backing up the video and audio signal saved in the HDD in the
SCSI HDD.
➂ TO DATE 2003 . 01 . 01 (Backup Finish Date)
You can set the date to finish backing up the video and audio signal saved in the HDD in the
SCSI HDD.
➃ TIME 12 : 00 : 00 (Backup Finish Date)
You can set the date to finish backing up the video and audio signal saved in the HDD in the
SCSI HDD.
➄ SYSTEM HDD 70.8GB/80.8GB[1] (Total space and free space of the main body
HDD)
It displays the DVR main body HDD space. The current message reads a HDD with the
80.8GB capacity(Free Space [70.8GB]/Total HDD Space [80.8GB]) and [1] indicates the
system can contain 2 HDDs in full but it is now using the first HDD. Here, the text, ‘70.8GB’
indicates the system consumed 10GB out of the total 80.8GB capacity.
➅ SCSI HDD 15.1GB /18.1GB [1] (Total space and free space of external SCSI
HDD)
It displays the number and capacity of the SCSI HDD connected to the SCSI Jack behind the
main body. The current message reads a HDD with the 18.1GB capacity(Free Space
[15.1GB]/Total SCSI HDD Space [18.1GB]) and [1] indicates the system can contain 2
external HDDs in full but it is now using the first HDD. Here, the text, ’15.1GB’ indicates
the system consumed 3GB out of the total 18.1GB capacity.
➆ START (Starting Backup)
After you type in the start and finish date/time of backup, press the JOG( ) or UP( ),
DOWN( ) button to move to START. Then you will see START highlighting. If you press
the SET/STILL button( ) now, a text, ‘SEARCH’ will pop up to search the image data
from the HDD to be backed up. Now, backup process will begin.
