Swann 4/9-SecuraNet SW243-4MB - Manual (Page 33)

29
Chapter 10: Specifications
4 / 9-Channel DVR
Items Descriptions
Video Standard NTSC PAL
Video Input/Output 4 Channels/2 Channels 9 Channels/1 Channel
Audio Input/Output 2 Channels/2 Channels 1 Channel/1 Channel
Resolution
NTSC:720X480@30fps(Each Ch)
PAL:720X576@25fps(Each Ch)
Monitoring
Features Full-D1 1-CH/4-CH/9-CH Display
Resolution
NTSC:720X240@60fps(4/9Ch.Total)
PAL:720X288@50fps(4/9Ch.Total)
Features
Variable Frame Rate/Variable QL per
Channel Recording
Quality 4-Level(Highest High Normal low)
Audio ADPCM2 CODEC
Video MPEG4
Motion Detection
Settable Window/Level
Microprocessor 32-bit RISC Processor
Network Interface TCP/IP(RJ45)
Network Monitor IE(Internet Explorer)
PTZ Interface RS485
USB Interface USB2.0
VGA Output Optional
Remote control IR remote control
Power supply DC 12V/3A
