23
[
●
]: the red dot next to the channel name indicates that the channel is being
recorded.
[A-REC]: indicates the current record schedule is set to be
NORMAL-RECORD mode.
[S-REC]: indicates the current record schedule is set to be
SENSOR-RECORD mode.
[N-REC]: indicates the current record schedule is set to be NO-RECORD
mode.
[39%]: indicates the percentage of hard disk space used.
7.2 Audio Recording
[ ]: indicates this video channel is bundled with an audio port, and the
audio output is on.
[ ]: indicates the audio output is off.
[
]: indicates the audio is being recorded and the audio output is on.
You could press [0] button on front panel to be mute mode for audio output.
The audio input can be still recorded while the output is mute.
7.3 Stop Recording
Press [
■
] stop button will stop recording. If password protection function is
enabled, system will prompt you to input password. Only correct password can
stop recording process.
7.4 Estimated Recording Length
Estimated record time based on 160Giga Byte HDD
Standard Quality 60fps 48fps 32fps 16fps 1fps
Highest 62
78 116 232 3720
High 88 110 165 330 5280
Normal 107 134 201 401 6420
NTSC
Lower 120 150 225 450 7200
Standard Quality 50fps 36fps 24fps 12fps 1fps
PAL Highest 64 89 133 267 3200
