background image

Pipeline HD Mini Series SATA Product Manual, Rev. A

31

Bit

Word 88

0

Ultra DMA mode 0 is supported.

1

Ultra DMA mode 1 is supported.

2

Ultra DMA mode 2 is supported.

3

Ultra DMA mode 3 is supported.

4

Ultra DMA mode 4 is supported.

5

Ultra DMA mode 5 is supported

6

Ultra DMA mode 6 is supported

8

Ultra DMA mode 0 is currently active.

9

Ultra DMA mode 1 is currently active.

10

Ultra DMA mode 2 is currently active.

11

Ultra DMA mode 3 is currently active.

12

Ultra DMA mode 4 is currently active.

13

Ultra DMA mode 5 is currently active.

14

Ultra DMA mode 6 is currently active.

Bit

Word 93

13

1 = 80-conductor cable detected, CBLID above V

IH

0 = 40-conductor cable detected, CBLID below V

IL
