78 US
Dimensions (width/height/depth) (Approx.)
430 Ч 157.5 Ч 310 mm
(17 Ч 6 1/4 Ч 12 1/4 inches)
including projecting parts
and controls
Mass (Approx.) 7.8 kg (17 lb 4 oz)
Speaker section
• Front speakers (SS-MSP900)
• Center speaker (SS-CNP680)
• Surround speakers (SS-SRP900)
Front/center speakers
Full range, magnetically
shielded
Surround speakers Full range
Speaker units 70 mm (2 7/8 inches)
cone type
Enclosure type Close type
Rated Impedance 6 ohms
Dimension (width/height/depth) (Approx.)
155 Ч 96 Ч 101 mm
(6 1/8 Ч 3 7/8 Ч 4 inches)
Mass (Approx.)
Front/center speakers
0.7 kg (1 lb 9 oz)
Surround speakers 0.5 kg (1 lb 2 oz)
• Sub woofer (SA-WP780)
AUDIO POWER
SPECIFICATIONS
POWER OUTPUT AND TOTAL
HARMONIC DISTORTION:
With 6 ohm loads, from 28 – 200 Hz; rated 120
watts, minimum RMS power, with no more
than 1% total harmonic distortion from 250
milliwatts to rated output.
Speaker system Active subwoofer,
magnetically shielded
Speaker unit 200 mm (7 7/8 inches)
cone type
Enclosure type Acoustically loaded bass
reflex
RMS output 200 W
Input LINE IN (input pin jacks)
Power requirements
Power consumption
Dimensions (width/height/depth) (Approx.)
270 Ч 331 Ч 380 mm
(10 3/4 Ч 13 1/8 Ч 15
inches)
Mass (Approx.) 8.3 kg (18 lb 5 oz)
Supplied speakers
• Front speakers (2)
• Center speaker (1)
• Surround speakers (2)
• Sub woofer (1)
Supplied accessories
FM wire antenna (1)
AM loop antenna (1)
Monaural audio cord (1)
Speaker cords
• Long (2)
• Short (3)
Coaxial digital cord (1)
Footpads
• Speakers (20)
• Sub woofer (4)
Remote commander RM-AAP017 (1)
R6 (size-AA) batteries (2)
Optimizer microphone (ECM-AC2 or
ECM-AC2a) (1)
Design and specifications are subject to
change without notice.
Area code Power requirements
U 120 V AC, 60 Hz
Area code Power consumption
U 80 W
For details on the area code of the
component you are using, see page 3.
