1. Cut the straps, then along the dotted line on the bottom of the box; lift the box over the unit and unpack.
2. Locate the hardware package. Remove the tools first. Remove the hardware for each step as needed to avoid
confusion. The numbers in the instructions that are in parenthesis (#) are the item number from the assembly
drawing for reference.
Pre-Assembly
XT
685
A
ssembly Instructions
Assembly Tools
#106. Combination M5 Allen Wrench/
Phillips Head Screw Driver
#107. M6 Allen
Wrench
#63. Safety Key
#18. Deck/Belt
Lubricant
#109. Phillips Head Screw Driver
To assist you in assembling your new Spirit Fitness treadmill, we have posted an assembly video at the following link:
http://www.spiritfitness.com/customerservice/video/treadmillvideos.html
Assembly Video
