Wine Storage Use & Care 17
subzero.com
Cleaning
CONDENSER CLEANING
Clean the condenser area every three to six months. The
cleaning schedule will depend on the amount of dust and
lint that accumulates in this area.
For models 424 and 424FS, the condenser is located
behind the kickplate. First, remove the kickplate to expose
the condenser area. Refer to the illustration below.
The condenser for models 427 and 427R is located behind
the kickplate/grille. Remove the screws holding the kick-
plate/grille. This assembly will slide forward easily, giving
you access to the condenser area. Refer to the illustration
below.
For model WS-30, the condenser is located behind the
grille. First, pull out on the bottom edge of the grill and tilt
forward. Refer to the illustration.
Use a soft bristle brush and vacuum hose to remove dust
and lint from the condenser area.
IMPORTANT NOTE: To avoid bending the condenser fins,
be sure to vacuum in the direction of the fins (up and
down).
Failure to clean the condenser could result in
temperature loss or mechanical failure or damage.
Before cleaning the condenser, shut off power to the
unit at the control panel. When you clean the
condenser, wear gloves to avoid injury from the
sharp condenser fins.
KICKPLATE
Location of condenser
(models 424 and 424FS). Location of condenser
(models 427 and 427R).
CONDENSER
Location of condenser
(model WS-30).
