Wine Storage Use & Care

Door Operation

DOOR CLOSING

The door of your wine storage unit has a spring-loaded

closure mechanism. As the door is closed, the door closer

engages to help close and seal the door.

90° DOOR STOP

If your wine storage unit is positioned in a corner, you may

want to limit the door opening to 90°.

IMPORTANT NOTE:

A 90° door stop is not available for

models 424 and 424FS.

For models 427 and 427R, a 90° door stop built into the

hinge system. You can easily actuate the stop by using a

blade-type screwdriver and rotating the brass cam in both

the top and bottom hinges. You must position both stops

at 90° if you want to safely use the door. You can go to the

maximum of a 105° door opening by using the screwdriver

and rotating the brass cam to the next stop. Refer to the

illustration below.

For model WS-30, a 90° door stop ships with the unit and

is located behind the flip-up grille. Refer to the illustration

below.

90° door stop
(models 427 and 427R).

90° door stop (model WS-30).

The door swing on models 427 and 427R may cause

severe finger pinching. Watch that fingers are not

placed in the door opening on the hinge side when

the door is open.
