10
Note : If a warning message pops up, click Continue
Anyway , then click Finish. Our driver has been
thoroughly tested in Windows for stability.
4. Remove the driver CD and restart Windows to
complete the driver installation.
Verify Proper Installation for Windows 2000/XP/
Server 2003
1. Right click My Computer and click Manage.
2. Select Device Manager.
3. Double click SCSI and RAID controllers, then
double click Silicon Image SiI 3114 ... Controller to
display driver properties.
4. A message This device is working properly is displayed
in the dialog box, the driver has been correctly
installed.
Bios Configuration
The Serial ATA 4-Channel PCI BIOS will appear everytime
your system starts up. If the bios doesn't show, please try
your controller in another PCI slot. During this (Post)
process, the bios will show up and indicate the devices
attached to it.
