Barracuda 7200.7 Serial ATA Product Manual, Rev. N

29

53

Words 54–58, 64–70 and 88 are valid

0007

H

54

Number of current logical cylinders

xxxx

H

55

Number of current logical heads

xxxx

H

56

Number of current logical sectors per logical track

xxxx

H

57–
58

Current capacity in sectors

xxxx

H

59

Number of sectors transferred during a Read Multiple or Write Multiple
command

xxxx

H

60–
61

Total number of user-addressable LBA sectors available

(see Section 2.2 for related information)

*Note: The maximum value allowed in this field is: 0FFFFFFFh
(268,435,455 sectors, 137 Gbytes). Drives with capacities over 137
Gbytes will have 0FFFFFFFh in this field and the actual number of user-
addressable LBAs specified in words 100-103. This is required for drives
that support the 48-bit addressing feature.

ST3200822AS = 0FFFFFFFh*
ST3160827AS = 0FFFFFFFh*
ST3160023AS = 0FFFFFFFh*
ST3160021AS = 0FFFFFFFh*
ST3120827AS = 234,441,648
ST3120026AS = 234,441,648
ST3120022AS = 234,441,648
ST380817AS = 156,301,488
ST380013AS = 156,301,488
ST380011AS = 156,301,488
ST340111AS = 78,165,360
ST340014AS = 78,165,360

62

Retired

0000

H

63

Multiword DMA active and modes supported (see note following this table)

xx07

H

64

Advanced PIO modes supported (modes 3 and 4 supported)

0003

H

65

Minimum multiword DMA transfer cycle time per word (120 nsec)

0078

H

66

Recommended multiword DMA transfer cycle time per word (120 nsec)

0078

H

67

Minimum PIO cycle time without IORDY flow control (240 nsec)

00F0

H

68

Minimum PIO cycle time with IORDY flow control (120 nsec)

0078

H

69–
74

ATA-reserved

0000

H

75

Queue depth

0000

H

76–
79

ATA-reserved

0000

H

80

Major version number

003E

H

81

Minor version number

0000

H

82

Command sets supported

306B

H

83

Command sets supported

4001

H

84

Command sets support extension

4000

H

85

Command sets enabled

30xx

H

86

Command sets enabled

0001

H

87

Command sets enable extension

4000

H

88

Ultra DMA support and current mode (see note following this table)

xx3F

H

89

Security erase time

0000

H

Word

Description

Value
