22

Barracuda 7200.7 Serial ATA Product Manual, Rev. N

Figure 5. Mounting dimensions—top, side and end view

4.000

(101.6)

5.787 (146.9898) max.

1.028 max

(26.111 max)

2.00

(50.80)

1.638

(41.605)

4.000

(101.6)

2 x 1.750

(2 x 44.45)

2 x 3.750

(2 x 95.25)

C

L of drive

[1]

Notes:
Dimensions are shown in inches (mm).
[1] Dimensions per SFF-8301 specification

[1]

[1]

[1]

1.122

+ .020

(28.499

+ .508)

[1]

[1]

[1]

[1]

C

L of conn. Datum B

.814

(20.676)

.138

(3.505)

.250 + .015

(6.35 + .381)

(3x both sides)

4.000

(101.6)

2 x 1.625

(2 x 41.28) [1]

Recommended
case temperature
measurement location

Recommended
case temperature
measurement location
