28 Barracuda 7200.7 Serial ATA Product Manual, Rev. N
4.3.1 Identify Device command
The Identify Device command (command code EC
H
) transfers information about the drive to the host following
power up. The data is organized as a single 512-byte block of data, whose contents are shown in the table on
page 27. All reserved bits or words should be set to zero. Parameters listed with an “x” are drive-specific or
vary with the state of the drive. See Section 2.0 on page 3 for default parameter settings.
The following commands contain drive-specific features that may not be included in the Serial ATA specifica-
tion.
Word Description Value
0
Configuration information:
• Bit 15: 0 = ATA; 1 = ATAPI
• Bit 7: removable media
• Bit 6: removable controller
• Bit 0: reserved 0C5A
H
1 Number of logical cylinders 16,383
2 ATA-reserved 0000
H
3 Number of logical heads 16
4 Retired 0000
H
5 Retired 0000
H
6 Number of logical sectors per logical track: 63 003F
H
7–9 Retired 0000
H
10–
19 Serial number: (20 ASCII characters, 0000
H
= none) ASCII
20 Retired 0000
H
21 Retired 0400
H
22 Obsolete 0000
H
23–
26 Firmware revision (8 ASCII character string, padded with blanks to end of
string) x.xx
27–
46 Drive model number: (40 ASCII characters, padded with blanks to end of
string) ST3200822AS
ST3160827AS
ST3160023AS
ST3160021AS
ST3120827AS
ST3120026AS
ST3120022AS
ST380817AS
ST380013AS
ST380011AS
ST340111AS
ST340014AS
47 (Bits 7–0) Maximum sectors per interrupt on Read multiple and Write mul-
tiple (16) 8010
H
48 Reserved 0000
H
49 Standard Standby timer, IORDY supported and may be disabled 2F00
H
50 ATA-reserved 0000
H
51 PIO data-transfer cycle timing mode 0200
H
52 Retired 0200
H
