Specifications

Amplifier section

Video section

Inputs

Outputs

General

System

Power
requirements

Power
consumption

AC outlets

Dimensions

Mass (Approx.)

Supplied
accessories

VIDEO 1, 2, 3, TV/LD

VIDEO IN:
1 Vp-p 75 ohms

VIDEO 1, 3 S VIDEO:

Y: 1 Vp-p, unbalanced,
sync negative
C: 0.286 Vp-p,
load impedance
75 ohms

VIDEO 1, 2, MONITOR

VIDEO OUT:
1 Vp-p 75 ohms

VIDEO 1, MONITOR

S VIDEO:
Y: 1 Vp-p, unbalanced,
sync negative
C: 0.286 Vp-p,
load impedance
75 ohms

Preamplifier section: Low-

noise NF type equalizer

Power amplifier section:

Pure-complimentary SEPP

220-230 V AC, 50/60 Hz

230 W

1 switched, total 100 W

430 x 157 x 355 mm
(17 x 6

1

/

4

x 14 inches)

10.5 kg (23 lb 3 oz)

Remote commander

(remote) (1)

Size AA (R6) batteries (2)

POWER OUTPUT
Stereo mode

Surround mode

Frequency
response

(DIN 1 kHz, 4 ohms)

90 W + 90 W

(DIN 1 kHz, 4 ohms)
Front:

90 W/ch

Centre:

90 W
(only in the PRO
LOGIC mode)

Rear:

25 W

PHONO: RIAA

equalization curve
±0.5 dB

TUNER, CD, TAPE/MD,

VIDEO 1, 2, 3, TV/LD:
10 Hz - 50 kHz dB

+0

–1

Impedance

50

kilohms

50

kilohms

S/N

(weighting

network,

input level)

75 dB**

(A, 2.5 mV)

82 dB**

(A, 150 mV)

Sensitivity

2.5 mV

200 mV

150 mV

PHONO
(MM)

CD

TAPE/
MD,
TUNER,
VIDEO 1,
2, 3, TV/
LD

Inputs

** ‘78 IHF

Outputs

Muting

BASS BOOST

TONE

TAPE/MD REC OUT,

VIDEO 1, 2 AUDIO
OUT: Voltage 150 mV,
Impedance 10 kilohms

MIX AUDIO OUT

Voltage: 2 V
Impedance: 1 kilohms

PHONES: Accepts low

and high impedance
headphones

– 20 dB

+10 dB at 70 Hz

±8 dB at 100 Hz and

10 kHz

Glossary

Centre mode

Setting of speakers to enhance Dolby Pro

Logic Surround mode. To obtain the best
possible surround sound, select one of the
following four centre modes according to
your speaker system.

• NORMAL mode

Select NORMAL mode if you have front
and rear speakers and a small centre
speaker. Since a small speaker cannot
produce enough bass, the bass sound of
the centre channel is output from the front
speakers.

• WIDE mode

Select WIDE mode if you have front and
rear speakers and a large centre speaker.
With the WIDE mode, you can take full
advantage of Dolby Surround sound.

• PHANTOM mode

Select PHANTOM mode if you have front
and rear speakers but no centre speaker.
The sound of the centre channel is output
from the front speakers.

Centre

speaker

Rear

speaker (R)

Rear

speaker (L)

Front

speaker (R)

Front

speaker (L)

Centre

speaker

Rear

speaker (R)

Rear

speaker (L)

Front

speaker (R)

Front

speaker (L)

Front

speaker (L)

Front

speaker (R)

Rear

speaker (R)

Rear

speaker (L)

Design and specifications are subject to
change without notice.
