25
User’s guide
E
SCC-B2311, SCC-B2310
Specifications
Item Description
Product Type Surveillance Camera
Broadcasting System NTSC STANDARD SYSTEM
Imaging Device
1/3”IT, S-HAD-CCD
Number of Effective
Pixels
SCC-B2311: 768(H) x 494(V)
SCC-B2310: 510(H) x 492(V)
Scanning 525 Line, 2:1 interlace
Line Frequency
INTERNAL : 15,734Hz(H) 59.94 Hz(V)
LINELOCK : 15,750Hz(H) 60 Hz(V)
Synchronous Mode
INTERNAL
LINE LOCK(AC 24V)
Horizontal Resolution SCC-B2311 : 540 TV Lines
SCC-B2310 : 330 TV Lines
S/N Ratio Approx. 50dB
Minimum Subject
Illumination
SCC-B2311 : 0.12 Lux (F1.2, 15 IRE, Sense-up off)
0.0009 Lux (F1.2, 15 IRE, Sense-up x 128)
SCC-B2310 : 0.06 Lux (F1.2, 15 IRE, Sense-up off)
0.0005 Lux (F1.2, 15 IRE, Sense-up x 128)
ALC/ELC
ALC
DC IRIS LENS
VIDEO LENS
ELC
Electronic Shutter Iris(max. 1/120Ksec)
FL(FLICKERLESS) OFF/ON
LSS(SenseUP) OFF/ON (Auto x 128)
DNR OFF/ON
DN (DAYNIGHT) OFF/ON (Auto)
Color Temp ATW(Auto White Balance)/AWC
BLC (Back Light Compensation) ON
AGC
OFF/ON
Signal Out
COMPOSITE VIDEO OUT
1V p_p 75Ω / BNC
Power AC24V ±10%(60Hz±0.3Hz), DC12V+10%~-5%
Power Consumption Approx. 3.0 Watts
Temperature
-10˚C ~ +50˚C
Moist ~90%
Dimension 65 (W)x 55 (H)x 138 (D)mm(BNC included)
Weight 440 g
