ERP2U Power Supply Design Guide, V2.31
- 16 -
If 240VA limiting is not a requirement for the power supply than all +12V outputs are common and may have the same wire
color (yellow).
6.1.2 +12V4 Baseboard Power Connector
STATUS
Required for 700W, 750W and 800W power levels
Systems that require more then 16A of +12V current to the baseboard will require this additional 2x2 power
connector. This is due to the limited +12V capability of the 2x12 baseboard power connector. +12V4 will power
this 2x2 connector.
Pin Signal 18 AWG color Pin Signal 18 AWG Color
1 COM Black 3 +12 V4 Yellow/Green Stripe
2 COM Black 4 +12 V4 Yellow/Green Stripe
If 240VA limiting is not a requirement for the power supply than all +12V outputs are common and may have the same wire
color (yellow
6.1.3 Required Peripheral Power Connectors
Connector housing: Amp 1-480424-0 or equivalent
Contact: Amp 61314-1 contact or equivalent
Table 9: Peripheral Power Connectors
Pin Signal 18 AWG Color
1 +12V4 Yellow
2 COM Black
3 COM Black
4 +5 VDC Red
1. If 240VA limiting is not a requirement for the power supply than all +12V outputs are common and may have the same
wire color.
6.1.4 Required Floppy Power Connector
Connector housing: Amp 171822-4 or equivalent
Table 10: P9 Floppy Power Connector
Pin Signal 22 AWG Color
1 +5 VDC Red
2 COM Black
3 COM Black
4 +12V4 Yellow
1. The +12V power to peripherals may be split between the second, third, or fourth +12V channel for the purpose of
limiting power to less than 240VA.
