SMOOTH 9.17HRO MOTORIZED TREADMILL
Visit us at: www.smoothfitness.com
6
PARTS LIST
NO. DESCRIPTION
QTY.
ORDER NO.
NO. DESCRIPTION
QTY.
ORDER NO.
1 Computer
1 9.17HRO-01
28
Upright Cross Brace Bolt
2
9.17HRO-28
2
Console Housing-
Upper
1 9.17HRO-02
29 Metal Cap
2
9.17HRO-29
3
Console Housing-
Bottom 1
9.17HRO-03
30
Upright-Left
1
9.17HRO-30
4 Rubber
Insert
4 9.17HRO-04
31
Console Tray
Support Tube
1 9.17HRO-31
5
Rubber Cap for
Audio Input
2 9.17HRO-05
32 Upright
Cross Brace
1
9.17HRO-32
6 Safety
Key
1 9.17HRO-06
33
M8 x 25mm Console Tray
Support Tube Bolt
1
9.17HRO-33
7 Console
Support
Tube 1 9.17HRO-07
34 Handlebar-Right
1 9.17HRO-34
8
#8 x 10mm Console
Housing Screw
11 9.17HRO-08
35 Front
Handlebar 1
9.17HRO-35
9
Console Support Tube
Fixing Plate
2
9.17HRO-09
36
Upright-Right 1
9.17HRO-36
10
#8 x 19mm
Computer Screw
5 9.17HRO-10
37 #8
x
15mm
Drill Screw
54
9.17HRO-37
11
M6 x 15mm
Console Fixing Screw
2 9.17HRO-11
38
Elevation Motor
Cover Board
1 9.17HRO-38
12
Handlebar Cover-
Left #1
1
9.17HRO-12
39
Power Cord
1
9.17HRO-39
13
Handlebar Cover-
Left #2
1 9.17HRO-13
40
M6 x 15mm
Bolt for Power Plate
2 9.17HRO-40
14
Handlebar Cover-
Right #2
1 9.17HRO-14
42 Power Plate
1
9.17HRO-42
15
Handlebar Cover-Right
#1 1
9.17HRO-15
43
Pivot
Bracket Screw
4
9.17HRO-43
16
#8 x 25mm Screw
8
9.17HRO-16
44 Pivot
Bracket
2 9.17HRO-44
17
Handlebar Fixing Plate
2
9.17HRO-17
45
Transport Wheel Shaft
2
9.17HRO-45
18
M8 x 25mm
Allen Head Bolt
6
9.17HRO-18
46
M14 x 90mm Bolt
2
9.17HRO-46
19
M8 x 15mm
Allen Head Screw
4 9.17HRO-19
47 Wire
Clip
1 9.17HRO-47
20
#8 x 10mm Screw
3
9.17HRO-20
48
Base Frame End Cap
4
9.17HRO-48
21
Console Tray
Fixing Plate
1
9.17HRO-21
49
Elevation Motor
1
9.17HRO-49
22 Console
Tray
1 9.17HRO-22 50 Cir-Clip
2 9.17HRO-50
23 Console
Tray
Cover
1 9.17HRO-23 51 Transport
Wheel
2 9.17HRO-51
24 Handlebar-Left
1 9.17HRO-24 52 5/16” x 10mm Screw
4
9.17HRO-52
25 Handlebar
Grip
2 9.17HRO-25 53
16 x 10mm
Spring Washer
1 9.17HRO-53
26
EKG Pulse Sensor
2
9.17HRO-26
54
M10 x 35mm Bolt
1
9.17HRO-54
27
Handlebar End Cap
2
9.17HRO-27 55 Base
Frame
1 9.17HRO-55
